- tienený LAN/sieťový kábel na pripojenie sieťových komponentov s 2 x RJ45 konektormi
- ideálne riešenie s minimálnym priestorom
- vonkajší štít: tienenie fólie
- s pozlátenými PIN
- štíhla úľava od napätia
- bez ochrany západky
- párová sekvencia príp. podľa EIA/TIA 568B
Technické špecifikácie
| AWG | 26/7 (uviaznutý) |
| Špecifikácia | CAT 5e |
| Priemer plášťa kábla (približne) | 5,4 mm |
| Trieda tienenia | F/UTP |
| Počet tienenia | 1 x |
| Kontaktovanie | EIA/TIA-568B |
| Označenia | WEEE, CE |
| Prevádzková teplota až | 60 °C |
| Prevádzková teplota od | -20 °C |
| max. šírku pásma | 100 MHz |
| Dĺžka kábla | 0,25 m |
| Ochrana proti zalomeniu | |
| Typ kábla | |
| Materiál plášťa kábla | |
| Materiál vnútorného vodiča | |
| Typ 1, tienenie | |
| Pripojenie, tienenie | |
| Ochrana západky | |
| Farba | |
| Jednotka spotreby | |
| Typ pripojenia | RJ45 samec 90° (8P8C) |
| Pripojenie 2, typ | RJ45 samec 90° (8P8C) |
Our CAT cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables and plugs. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
- Prewired, shielded CAT 5e LAN cable with 2x RJ45 plugs for connecting network components
- Foil screen (F/UTP) prevents interference from external sources (crosstalk) and provides ideal signal distribution with minimal losses.
- The CAT 5e network cable with 90° right angle RJ45 connectors (without latch protection) is an ideal solution in confined spaces.
- High-quality copper-clad aluminium wire (CCA) and gold-plated contacts guarantee an excellent, powerful network connection.
- Patch cable with overmoulded slimline bend protection
- Network connector: pair sequence according to EIA/TIA 568B
- Cable construction: twisted pair cable
Technical specifications
| Connection, type | RJ45 male 90° (8P8C) |
| Connection 2, type | RJ45 male 90° (8P8C) |
| Connection, shielding | yes |
| Latch protection | no |
| Kink protection | both sides |
| Cable type | round cable |
| Inner conductor material | CCA (copper-clad aluminium) |
| Type 1, shielding | foil (aluminium) |
| Material cable sheath | PVC |
| Color version | white |
| Color | white |
| Consumption Unit | 1 pc. bulk |
| Packaging type | Cable Tag |
| Contacting | EIA/TIA-568 B |
| Specification | CAT 5e |
| Cable length | 0.25 m |
| Cable sheath diameter (approx.) | 5.4 mm |
| Shielding class | F/UTP |
| AWG | 26/7 (stranded) |
| Number of shieldings | 1 x |
| bending radius > | 54 mm |
| max. transmission rate | 1 Gbit/s |
| max. bandwidth | 100 MHz |
| Markings | WEEE, CE |
| Operating temperature from | -20 °C |
| Operating temperature up to | 60 °C |
Kategória
cat. 5e / class D 100MHz / 1000 BASE-T
Tienenie
F/UTP
Dĺžka
0.25m
Farba
biela
Materiál vodiča
CCA (Copper Clad Aluminum) - pomedený hliník
Predlžovací
nie
Zapojenie
1:1 podľa EIA / TIA 568
LSOH/LSZH bezhalogénový
nie
Vhodný do exteriéru
nie
Uhlový konektor/konektory
Uhlové konektory (2x90°)
Slim / Plochý
Nie
Certifikovaný kábel
nie
Flexibilný
nie
Montáž na panel
nie
Ochrana západky konektora
nie
Typ vodiča
lanko
