- Plne tienené puzdrom zo zliatiny zinku
- Zapojenie T568A a T568B
- Výkon kanála C8 overený
- Prierez kábla: 22AWG až 26AWG
- Vonkajší priemer kábla: 7,0 až 8,5 mm
- Vhodné pre aplikácie PoE plus (IEEE 802.3at).
- Jednoduchá, rýchla a spoľahlivá inštalácia
Technické špecifikácie
| Skupina produktov | Technológia pripojenia TP |
| Typ produktu | Konektory RJ-45 |
| Farba | striebro |
| Typ štítu | Preverené |
| Kvalita prenosu | Cat8.1 / Trieda I |
| samostatné uvoľnenie napätia | Áno |
| Hmotnosť | 19,7 g |
- Full shielded with zinc alloy housing
- T568A & T568B wiring
- C8 channel performance vertified
- Cable wire gauge : 22AWG to 26AWG
- Cable outer diameter : 7.0 to 8.5mm
- Suitable for the PoE plus (IEEE 802.3at) applications
- Easy, quick and reliable installation
Technical specifications
| Product group | Connection technology TP |
| Product type | Connectors RJ-45 |
| Colour | silver |
| Scope of delivery | 1x plug |
| Shield type | Screened |
| Transfer quality | Cat8.1 / Class I |
| Quantity of ports | 1 |
| Side 1 Connector Type | RJ-45 |
| Side 1 Connector Gender | Male |
| separate strain relief | yes |
| Operating temperature min. | -10 |
| Operating temperature max. | 60 |
| Height | 18.4 |
| Width | 13.8 |
| Depth | 50.2 |
| Weight | 19.7 |
| Height of packaging (single piece) | 50 |
| Width of packaging (single piece) | 20 |
| Depth of packaging (single piece) | 50 |
| Package weight (single piece) | 0.02 |
| Gross weight | 0.02 |
