S/FTP (PiMF) Patchkábel LSOH 20m cat.8, sivý, Cu, 40GBit/s, 2000Mhz

S/FTP (PiMF) Patchkábel LSOH 20m cat.8, sivý, Cu, 40GBit/s, 2000Mhz

Kód: {{ productModel }}
Výrobca: Goobay
Kat. č.: W.55143
EAN: 4040849551437

Cat. 8.1 (Cat. 8.1) network/ LAN cables are used for 25/40GBASE-T applications, with a transmission bandwidth ..... celý popis

Externý sklad
58,82 € s DPH 49,02 € bez DPH
Cat. 8.1 (Cat. 8.1) network/ LAN cables are used for 25/40GBASE-T applications, with a transmission bandwidth of up to 2 GHz (four times the bandwidth of Cat. 6A).Green/transparent RJ45 plug contacts allow easy optical differentiation into Goobay patch cables category CAT 8.1.Length indication on the molded bend protection sleeve with strain relief and a latching lever protection, which prevent the cable from snagging and breaking off the latching lever from the plug, meet all the requirements of a wide variety of applications.
  • HighSpeed network cable Appropriate for 25/40G Base-T Ethernet networks (40GB-capable) and downward compatible, Ethernet (10BASE-T, 100BASE-TX, 1000BASE-T)
  • Cat 8.1 raw cable up to 2000 MHz / 2 GHz
  • New type of RJ45 plug as per industry standard with 50µ gold-plated contact surfaces (PINs)
  • suitable for Power over Ethernet (PoE/PoE+)
  • Double-shielded LAN/network cable: wire pair shielding: PIMF (pair in metal foil) + overall shielding: mesh
  • especially for game consoles with high resolution image (4k/120Hz, 8k/60Hz) such as Sony Playstation 5 (PS 5) or Microsoft Xbox X

Technical specifications

AWG24/7 (stranded)
Kink protectionboth sides
SpecificationCAT 8.1
Cable sheath diameter (approx.)8.2 mm
Material cable sheathLSZH
inner conductor, core diameter0.2
Inner conductor materialCU (copper)
LSZH compliantyes
Shielding classS/FTP (PiMF)
Number of shieldings2 x
Type 1, shieldingfoil (alu) PiMF
Type 2, shieldingbraid (alu) overall shield
Connection, housing materialPVC
Connection, contact materialgold-plated 50µ
Connection, shieldingyes
Connection, typeRJ45 industry industry female (8P8C)
Connection 2, typeRJ45 industry industry female (8P8C)
ContactingEIA/TIA-568B
Latch protectionboth sides
MarkingsWEEE, CE
Colorgrey
MaterialLSZH
Operating temperature up to75 °C
Operating temperature from-20 °C
Color versiongrey
Cable length20 m
Cable typeCat 8.1 raw cable
Parametre
Zapojenie
1:1 podľa EIA / TIA 568
Tienenie
S/FTP (PiMF)
LSOH/LSZH bezhalogénový
áno
Farba
sivá
Materiál vodiča
meď
Kategória
cat. 8 / class G
Dĺžka
20m
