The Cat.8.1 patch cable is suitable for 25GBASE-T and 40GBASE-T applications based on RJ45. The Cat.8.1 has a frequency range of up to 2000MHz and a maximum transmission distance of currently 30m.

Cable: S/FTP 4x2xAWG24/7
Jacket material: LSZH
Outer diameter: 8mm
Transmission standards: 25Gbit, 40Gbit

PRODUCT FEATURES
Category: 8.1
Type of connector connection 1: RJ45 8(8)
Type of connector connection 2: RJ45 8(8)
Connector type: RJ45 Standard
Pin assignment: 1:1
Allocation: acc. TIA/EIA 568B
Type: Shielded
Length imprint: yes
Anti-kink sleeve: plugged in
Locking lever: yes
Mating cycles: ≥750
Bending radius: >40 mm
Conductive shield: Selected shield contact
Cable structure: S/FTP
Cable construction: 4x2
AWG-size/strands per core: 24/7
Conductor Material: Copper
Jacket material: LSZH
Printing: CAT8 S/FTP 4x2x24AWG/7 LSZH 2000MHz ISO11801
Outer diameter of the cable: 8 mm
Impedance: 100 ±15 Ω
Insulation resistance: 10 MΩ
Contact resistance: 5 mΩ
Bandwidth: 2000MHz
