- metalizované plastové puzdro
- LSA konektory
- je možná inštalácia bez použitia náradia
- STP - tienená verzia
- pre CAT 6/ CAT 6A/ CAT 7 sieťový/LAN kábel AWG 22-26
- vhodné pre PoE+ podľa IEEE 802.3at
Technické špecifikácie
| Trieda tienenia | STP |
| Označenia | CE |
| Výška | 23 mm |
| Dĺžka | 83,7 mm |
| šírka | 37 mm |
| max. šírku pásma | 600 MHz |
| Špecifikácia | CAT 6 |
| Typ pripojenia | pre konektory IDC (bez nástrojov) |
| Farba | čierna |
| Jednotka spotreby | 1 ks. v polybagu |
| Farebné prevedenie | čierna |
- Shielded CAT connection module (STP) for extending or linking 2x LAN installation cables
- CAT connector to reconnect damaged cables without re-routing an entire cable segment
- Suitable for unassembled patch cables with AWG 22-26 (CAT 6, CAT 6A and CAT 7)
- IDC connectors for tool-free assembly by solderless, screwless and stripping-free connection technology IDC mounting)
- Max. data transmission of 600 MHz guarantees an excellent network connection.
- Connection box consists of a high-quality, metallised plastic housing
- The network cable connection module is suitable for PoE+ applications (IEEE 802.3at).
Technical specifications
| Connection, type | for IDC connection (toolless) |
| Color version | black |
| Color | black |
| Consumption Unit | 1 pc. in polybag |
| Packaging type | Bulk |
| Specification | CAT 6 |
| Shielding class | STP |
| max. bandwidth | 600 MHz |
| Markings | CE |
| Length | 83.7 mm |
| Width | 37 mm |
| Height | 23 mm |
