This Cat.6 data cable from EFB-Elektronik supports 5Gbit. Since it is a Cat.6 network cable, it offers a frequency range of up to 250MHz, which provides high data transmission performance.

Ě Cover fire protection requirements in compliance with standards Í flame-retardant cable behaviour according to IEC60332-1 reduces the spread of fire in the event of a fault and supports compliance with common installation specifications.
Ě Ensure reliable 5 Gigabit connections Í gold-plated contact surfaces reduce contact resistance and contact corrosion, which supports signal quality and thus stable 5Gbps transmission.
Ě Reliable 250MHz bandwidth performance ensures high-speed data transmission.

Product Description
The unshielded design in this U/UTP patch cable enables cost-efficient networking in low-interference environments while providing high flexibility for easy installation. The temperature range of the cable is -20 Í 60 řC. The wide range of possible applications is supported by the bending radius of >30 mm. The Ethernet cable is IP20 rated. The polyvinyl chloride (PVC) jacket is a flexible standard jacket for network applications, without special fire protection properties.

Technical details
Ě Cat.6
Ě Connector: RJ45 8(8) to RJ45 8(8) with RJ45 connectors
Ě Shielding: U/UTP cable with 4x2 x AWG24/7
Ě Cable shape: round
Ě Pin assignment: 1:1 according to TIA/EIA 568B
Ě Gold-plated contacts
Ě Sheath: Polyvinyl chloride (PVC) sheath material
Ě Outer diameter: 5.9 mm
Ě With an injected anti-kink grommet
Ě Fire protection: flame-retardant according to IEC60332-1
Ě Degree of protection: IP20
Ě Mating cycles: =750
Ě With length print
Ě Brand: EFB-Elektronik
