The Cat.6 data cable from EFB-Elektronik supports data transmissions of up to 5Gbit. Because it is a Cat.6 network cable, it offers a frequency range up to 250MHz, which enables high data transmission performance.

Ì Cover fire protection requirements in compliance with standards Í flame-retardant cable behaviour according to IEC60332-1 reduces the spread of fire in the event of a fault and supports compliance with common installation specifications.
Ì Increased safety in the event of a fire Í low smoke generation after IEC61034 helps to keep escape routes as low in smoke as possible in the event of a fire, and the halogen-free materials according to IEC60754-2 reduce the development of corrosive fire gases.
Ì Ensure reliable 5 Gigabit connections Í gold-plated contact surfaces reduce contact resistance and contact corrosion, which supports signal quality and thus stable 5Gbps transmission.

Product Description
The unshielded design in this U/UTP data cable enables cost-efficient networking in low-interference environments while providing high flexibility for easy installation. It can be used in a temperature range of -20 Í 60 øC. The wide range of possible applications is supported by the bending radius of >30 mm. The LAN cable has an IP20 rating. The LSZH jacket is halogen-free and low-smoke. In the event of a fire, it minimizes smoke development and increases indoor safety.

Technical details
Ì Cat.6
Ì Connector: RJ45 8(8) to RJ45 8(8) with RJ45 connectors
Ì Shielding: U/UTP cable with 4x2 x AWG24/7
Ì Cable shape: round
Ì Pin assignment: 1:1 according to TIA/EIA 568B
Ì Gold-plated contacts
Ì Sheath: LSZH sheath material
Ì Outer diameter: 5.9 mm
Ì With an injected anti-kink grommet
Ì Fire protection: flame-retardant according to IEC60332-1, low-smoke according to IEC61034, halogen-free according to IEC60754-2
Ì Degree of protection: IP20
Ì With locking lever protection
Ì Mating cycles: =750
Ì With length print
Ì Brand: EFB-Elektronik
