• Continuously emulates HDMI® EDID information
• Supports resolutions up to 7680x4320@60Hz or 3840x2160@120Hz with additional support for HDR
• Used cloned data in up to 8 pre stored resolutions/timings
• Headless connection (no monitor connection required)
• 3 year warranty

The Lindy HDMI® 8K60 EDID Feeder adapter is designed for systems that require an uninterrupted signal to overcome EDID related issues that commonly occur when using AV equipment such KVMs, Extenders, Splitters&Switches. With the small-scale and minimalistic design, this is a handy connectivity solution for both AV and IT installers to ensure legacy and new HDMI® equipment works seamlessly with no compromise on performance.

With support for resolutions up to 7680x4320@60Hz or 3840x2160@120Hz HDR (Via cloning), HDCP 2.3 pass through, this emulator is perfect for use with any HDMI® device.

This adapter provides a fast and reliable way to clone EDID data directly from an HDMI® display, ensuring that your graphics card always receives accurate and consistent display information. By capturing the displays EDID settings, it helps eliminate common compatibility issues such as incorrect resolutions, display drop outs, or handshake problems making it ideal for professional AV installations, testing environments, and system integration work.

A key advantage of this unit is its eight independent EDID memory slots, allowing you to store and manage up to eight individual EDID profiles at once. Each slot can hold a different EDID configuration, giving you the flexibility to switch between multiple monitors, resolutions, and setups without needing to re clone every time. Selection is made easily and instantly using the on board DIP switch, providing full control and a clear, reliable workflow for multi display environments or repeated installation tasks.

The cloning process takes less than 10 seconds, meaning you can capture, store, and deploy EDID data quickly, perfect for time sensitive or high volume installation work. For a full technical breakdown and operating instructions, please refer to the Technical Information section.

The terms HDMI, HDMI High Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc

Specification

• AV Interface: HDMI®
• Interface Standard: 2.1
• Supported Bandwidth: 48Gbps
• Maximum Resolution: 7680x4320@60Hz 4:4:4 10Bit
• Audio EDID: Sample size : 16 to 24 bits, sample rates : 32kHz up to 192kHz.
• HDCP Support: HDCP 2.3
• Special Features: Headless connection (No Monitor connection required)

Connectors

• Input: HDMI® Male
• Output: HDMI® Female
• Power: Via HDMI® source Interface
• Data: USB-C

Physical Properties

• Dimensions WxDxH: 64.5 x 22.5 x 11mm (2.53 x 0.88 x 0.43in)
• Housing Material: ABS
• Net Weight: 0.013Kg (0.028lb)
• Operating Temperature: 0degC - 50degC (deg32F - deg122F)
• Storage Temperature: -20degC - 70degC (deg-4F - deg158F)
• Humidity: 0-80% RH (non-condensing)
• Colour: Black

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 136 x 146mm (5.35 x 5.74in)

• Gross Weight: 0.036Kg (0.079lb)
• Warranty (Years): 3
• Product Compliance:
• Product Compliance: CE, FCC, RoHS, REACH, TAA

Package Contents

• EDID Emulator
• Lindy Manual

Purchasing Information

• No.: 32105
• EAN: 4002888321051
