- Funguje s akoukoľvek grafickou kartou, ktorá má výstup DP a funguje úplne rovnako ako skutočný LCD monitor
- Je možné simulovať až 4K rozlíšenie, 3840 x 2160 pri 17 Hz
- Kompaktný dizajn, malé rozmery
- Plug & Play
- Hot Plug
- Žiadne ovládače, žiadna konfigurácia nie je potrebná
Technické špecifikácie
| Skupina produktov | Adaptéry, terminátory, konvertory |
| Typ produktu | Adaptér DisplayPort-DisplayPort |
| Farba | čierna |
| Rozhranie | DP |
| Vstupy | 1 |
| Max. rozlíšenie (nom.) | 3840 x 2160 pri 17 Hz |
| Hmotnosť | 5,6 g |
| Výška balenia (jeden kus) | 10 mm |
| Šírka balenia (jeden kus) | 20 mm |
| Hĺbka balenia (jeden kus) | 40 mm |
| Hmotnosť balenia (jeden kus) | 0,002 kg |
The EDID emulator is plugged into the output of the graphics card and behaves just like a real monitor in relation to the graphics card. This enables for example the monitorless operation of PC and server systems.
- Works with any graphics card that has DP output and acts exactly the same as real LCD monitor
- Up to 4K resolution can be simulated, 3840x2160@17Hz
- Compact design, small size
- Plug & Play
- Hot Plug
- No drivers, no configuration needed
Technical specifications
| Product group | Adapters, Terminators, Converters |
| Product type | DisplayPort-DisplayPort Adapter |
| Colour | black |
| Interface | DP |
| Inputs | 1 |
| Max. resolution (nom.) | 3840x2160 @17Hz |
| Weight | 5.6 |
| Height of packaging (single piece) | 10 |
| Width of packaging (single piece) | 20 |
| Depth of packaging (single piece) | 40 |
| Package weight (single piece) | 0.01 |
| Gross weight | 0.01 |
-
