- neukončený flexibilný dátový/patch kábel pre domáce/vnútorné použitie
- netienený krútený kábel LAN
- Ideálne pre SOHO aplikácie (malá kancelária, domáca kancelária) do max. prenosová dĺžka 40 m!
- Ideálne pre SOHO aplikácie (malá kancelária, domáca kancelária) do max. prenosová vzdialenosť 40 m!
Technické špecifikácie
| AWG | 26/7 (uviaznutý) |
| Typ kábla | okrúhly kábel |
| Špecifikácia | CAT 5e |
| Priemer plášťa kábla (približne) | 5 mm |
| Materiál plášťa kábla | PVC |
| Materiál vnútorného vodiča | CCA (hliník potiahnutý meďou) |
| Trieda tienenia | U/UTP |
| Označenia | ECA_CPR, CE, SOHO |
| Farba | sivá |
| Jednotka spotreby | 1 ks. káblový navijak |
| Impedancia | 100 O |
| max. šírku pásma | 100 MHz |
| Požiarna trieda (CPR) | Eca |
| Dĺžka kábla | 100 m |
| Merač mierka | |
| Farebné prevedenie | sivá |
Our patch cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
- Unshielded twisted-pair LAN cable for the small office and working from home (SOHO and WFH applications)
- Unterminated patch cable for assembly and installation with IDC connection technology
- Flexible cable for indoor assembly with a maximum transmission length of 40 m
- High-quality copper-clad aluminium wire (CCA) guarantees an excellent and powerful network connection.
- Sturdy PVC cable sheathing protects the Ethernet cable from breakage.
- Complies with the Construction Products Regulation (CPR) and Eca fire protection class
Technical specifications
| Cable type | round cable |
| Material cable sheath | PVC |
| Meter scaling | yes |
| Inner conductor material | CCA (copper-clad aluminium) |
| Fire class (CPR) | Eca |
| Color | grey |
| Color version | grey |
| Consumption Unit | 1 pc. cable reel |
| Packaging type | Cable spool-drum |
| Specification | CAT 5e |
| Cable length | 100 m |
| Diameter of insulated conductor | 0.9 mm (+/-0.05) |
| AWG | 26/7 (stranded) |
| max. bandwidth | 100 MHz |
| usable up to cable length | 40 m |
| Cable sheath diameter (approx.) | 5 mm |
| Shielding class | U/UTP |
| max. transmission rate | 1 Gbit/s |
| Impedance | 100 O |
| Markings | ECA_CPR, CE, SOHO |
Dĺžka
100m
Kategória
cat. 5e / class D / 100MHz
Typ
lanko
Materiál vodiča
CCA (Copper Clad Aluminum) - pomedený hliník
Farba
sivá
Tienenie
U/UTP
LSOH/LSZH bezhalogénový
nie
Vhodný do exteriéru
nie
Dvojitý (Duplex)
nie
Hrúbka vodiča (AWG)
AWG26
